T-Slot Extruded Seals

Looking for something else? Need something you don't see? Ultrafab offers a wide range of products beyond those shown here. Contact us for more information.

Used in aluminum or vinyl windows at the top and bottom of single or double hung designs. Also used as a frame or sash seal in casement windows, or on the meeting rail of double and single hung windows.

TPE Profiles with easy slide base for fast installation.

TO ORDER: See Part Ordering Specification Sheet.

Available for sale online in 34′ lengths.

$13.50$105.00

Clear
SKU: N/A Categories: ,

Description

  • High quality, UV stabilized TPE material offers excellent compression set resistance
  • Available with our UltraGlide® low friction formulation
  • Superior weatherability and chemical resistance
  • AAMA Rating
  • Easy to install
  • Standard and custom backing widths
  • Insert by hand, or use one of Ultrafab’s insertion machines with our patented T-Loc® backing
  • Sash drill machine available to reduce insertion labor
  • TPE T-slot bulbs can be welded
  • Five standard colors, custom colors available
  • Cut to length or reeled
  • Available with Ultra-Grip® backing which has legs on the backing to hold the backing in place. Ultra-Grip® is designed to be inserted using Ultrafab’s patented automation equipment which can be used by either fabricators or extruders
  • LOW COST ALTERNATIVE TO FOAM

E201

.DWG, .DXF

E202

.DWG, .DXF

E203

.DWG, .DXF

E204

.DWG, .DXF

E205

.DWG, .DXF

E206

.DWG, .DXF

E207

.DWG, .DXF

E208

.DWG, .DXF

E209

.DWG, .DXF

E215

.DWG, .DXF

E218

.DWG, .DXF

E219

.DWG, .DXF

E221

.DWG, .DXF

E230

.DWG, .DXF

E231

.DWG, .DXF

E233

.DWG, .DXF

E235

.DWG, .DXF

E251

.DWG, .DXF

E252

.DWG, .DXF

E260

.DWG, .DXF

E270

.DWG, .DXF

E271

.DWG, .DXF

E272

.DWG, .DXF

E273

.DWG, .DXF

E274

.DWG, .DXF

E275

.DWG, .DXF

E276

.DWG, .DXF

E277

.DWG, .DXF

E708

.DWG, .DXF

S201

.DWG, .DXF
